EM-Tec conductive silver, nickel or carbon microtip pen


EM-Tec AG20 conductive silver microtip pen

Introduction

The EM-Tec conductive pen enables writing conductive tracks, traces and lines on non-conductive materials. Ideal for making conductive paths for SEM samples, making visible marking on SEM samples, repairing defective tracks on circuits or for prototyping. The ink in the microtip pen is filled with either silver, nickel or carbon polymer which exhibits excellent adhesion properties on most materials. The conductive traces dry fast and conductivity is achieved when the ink is cured. The conductive traces can be used on flexible substrates. The cured traces can be easily removed with acetone
Features and benefits:

  • Creates durable, reliable and conductive traces
  • Micro-tip of 0.8mm with typical trace width of 1.5 – 2.0 mm
  • Visible & conductive marking of SEM samples
  • Dry to touch in 1 minute at room temperature
  • Strong corrosion resistance
  • Service (use) temperature -40 to 120 °C
  • Does not contain toluene, xylene or MEK


There is a choice of three materials for the EM-Tec conductive pens:
1 – EM-Tec AG20 silver conductive micro-tip pen with silver filled ink for best results. Makes excellent conductive traces and highly visible markings on SEM samples
2 – EM-Tec NI20 nickel conductive micro-tip pen with nickel filled ink for less demanding applications to make conductive traces and visible markings on SEM samples
3 – EM-Tec C20 carbon conductive micro-tip pen with carbon filled ink is a cost-effective option to make conductive traces and conductive markings on SEM samples

Instructions for use:
Although the silver ink has been formulated to resist hard-packing, it is recommend to shake well before use until the ball inside freely moves inside. Hold pen at an angle and depress tip against surface; draw pen across surface while gently squeezing the barrel of the pen. Clean tip, replace can and store with the tip up after use. Let dry 1 minute before handling or het cure.

Specifications of the EM-Tec silver, nickel or carbon conductive micro-tip pens

Product

EM-Tec AG20

EM-Tec NI20

EM-Tec C20

Product number

15-002520

15-004120

15-001120

Material

Silver filled polymer

Nickel filled polymer

Carbon filled polymer

System

Single component, solvent

Single component, solvent

Single component, solvent

Fill

9 grams

7.5 grams

4.4g

Resisitivty

1x10-4 Ω.cm

4 x 10-3 Ω.cm

6.3 x 10-1 Ω.cm

Service temperature

-40 to 120 °C

-40 to 12 0°C

-40 to 120 °C

Dry to touch

1 minute

1 minute

1 minute

Cure time @ 22°C

24 hours

24 hours

24 hours

Cure time @ 65°C

30 minutes

30 minutes

30 minutes

Approx. track length

50m

30m

74m

Viscosity

1060 cP

160 cP

114 cP

Density

1.83 g/mL

1.51 g/mL

0.898 g/mL

Solids

58%

57%

15%



Ordering information for EM-Tec conductive silver, nickel or carbon microtip pen

*Prices without VAT, but within the EU, we have to check for valid VAT-ID.

15-002520.png EM-Tec AG20 conductive silver pen with 0.8mm microtip
EM-Tec AG20 conductive silver pen with 0.8mm microtip
Product # Unit Price* Add to Quote / Order
15-002520 each €59,50
Qty:

Hazardous Symbol Explanation

hazard fee symbol = Hazard Shipping Fee
Cg = Suspected Carcinogen
F = Flammable
I = Irritant
S = Sensitizer
T = Toxic
Extra info 15-002520 :   Cg | F | I | SDS pdf download



15-004120.jpg EM-Tec NI20 conductive nickel pen with 0.8mm microtip
EM-Tec NI20 conductive nickel pen with 0.8mm microtip
Product # Unit Price* Add to Quote / Order
15-004120 each €29,50
Qty:

Hazardous Symbol Explanation

hazard fee symbol = Hazard Shipping Fee
Cg = Suspected Carcinogen
F = Flammable
I = Irritant
S = Sensitizer
T = Toxic
Extra info 15-004120 :   Cg | F | I | SDS pdf download



15-001120.jpg EM-Tec C20 conductive carbon pen with 0.8mm microtip
EM-Tec C20 conductive carbon pen with 0.8mm microtip
Product # Unit Price* Add to Quote / Order
15-001120 each €25,50
Qty:

Hazardous Symbol Explanation

hazard fee symbol = Hazard Shipping Fee
Cg = Suspected Carcinogen
F = Flammable
I = Irritant
S = Sensitizer
T = Toxic
Extra info 15-001120 :   Cg | F | I | SDS pdf download
