Micro-Tec DM402 Digital Microscope
easy to use and ideal for sample preparation, small parts inspection and assembly


Introduction

    The Micro-Tec DM402 digital microscope

The Micro-Tec DM402 digital microscope with a large and bright LCD viewing screen is the ideal tool for precise sample preparation, inspection, micro-assembly and education. Viewing the image on the screen is less strenuous than using a stereo microscope with oculars and makes hand-eye coordination much easier. The Micro-Tec DM402 combine a bright 10” screen with the image sensor, focusing tube and top illumination in a single compact unit. The large 10” high resolution LCD screen coupled to the ultra-high resolution image sensor enables detailed full colour images which can be easily shared with colleagues. The DM402 also offers photo and video capture which can be stored on a micro SD card. Top illumination is provided by integrated LED’s in the imaging tube and a twin flexible gooseneck with LEDs provides angled side illumination to enhance sample details. With a maximum distance of 16cm, larger objects or assemblies can be easily investigated. HDMI and USB outputs are provided for connecting a larger screen or projector or for connecting a computer. The Micro-Tec DM402 includes a comprehensive choice of image settings and colour setting (incl. negative imaging) to improve image quality and to enhance imaging details


Features of the Micro-Tec DM402 Digital Microscope:

  • Large 10” (25cm) LCD screen with large viewing angle
  • High resolution imaging sensor with 8 integrated white light LEDs
  • Optical magnification range 2-70x with additional 3x digital zoom
  • Total magnification range 2-1200x
  • High resolution image sensor up to 24M (5600x2400 pixels)
  • Stand with 25cm post and twin flexible gooseneck LEDs
  • Photo and video capture on micro SD card
  • Additional USB and HDMI output
  • Comprehensive Image control functions


Specifications of the Micro-Tec DM402 digital microscope:

Viewing screen

10 inch/250mm, 1024x800 pixels, full colour IPS-LCD monitor

Photo resolution, pixels

5600x4200, 5200x3900, 4640x3480, 4032x3024, 3648x2736, 3264x2448, 2952x1994, 2048x1536, HD 1920x1080, VGA 640x480 & 1280x960

Video resolution, pixels

2880x2160Px24fps, 2560x1440Px30fps, 1920x1080Px60fps/30fps & 1280x720P x 120fps/60fps.30fps

Imaging

Live on monitor, photo storage and video capture

Illumination integrated

8 white light LEDs in the lens tube. 0-100% built-in dimmer in LCD screen

Illumination, twin goose neck

Flexible goose neck with LEDs , mounted on microscope stand, 8 brightness levels

Microscope stand

200x178 mm base plate with 250 mm tall post

Output

LCD screen + HDMI + USB + micro SD card (Max.64GB)

Image control

Resolution, Sharpness, White balance, Colour, ISO, Exposure, Positive/Negative, Quality & Contrast

System control

Push buttons on monitor+ additional remote control

Power

AC Adapter 5V/2A/10W with USB output. Input 100-240V / 0.35A / 50/60Hz


Scope of delivery for the Micro-Tec DM402 digital microscope:
1 x  Micro-Tec DM402 2K HDMI Digital Microscope
1 x Base stand with 250mm tall post
1 x Flexible twin goose neck illumination
1 x Illumination control with 3 in 1 cable
1 x USB cable for computer
1 x Remote control
1 x Power supply cable
1 x AC Adaptor
1 x Transmitted light stage
5 x Prepared slides
1 x Installation tool kit
1 x English manual
1 x 32GB Micro SD card



Ordering information for the Micro-Tec DM402 digital microscope

*Prices without VAT, but within the EU, we have to check for valid VAT-ID.

Micro-Tec DM402 digital microscope with stand and dual illumination system, 100-240V Micro-Tec DM402 digital microscope with stand and dual illumination system, 100-240V
Product # Unit Price* Add to Quote / Order
51-005402 each €385,00
